Aquinox Stainless Steel 45° Plain End Elbow (M Profile)

Product Overview and Specification

EN Standard Compliant – Engineered for Durability in Aquinox Fitting Systems

Stainless Steel 45° Elbow with Plain End - Side View

Stainless Steel 45° Elbow with Plain End - Detailed View

Dimensional Specifications

OD (mm)	THK (mm)	L (mm)	Z (mm)
15	1.50	33	10.5
18	1.50	34	11.5
22	1.50	38	15
28	1.50	42.5	17.5
35	1.50	49	20
42	1.50	59	25
54	1.50	71	32
76.1	2.00	98	43
88.9	2.00	112	49
108	2.00	138	61

—

Advantages of Aquinox Fittings

**Easy Assembly**: Practical and convenient (**efficient installation in seconds**).
**Quick Installation**: Saves hours of labor, ideal for large projects.
**Safe and Approved**: Guaranteed system with certifications for water, gas, and industrial use.
**Simplified Labour**: No need for specialized personnel (just a press tool).
**Flameless Connection**: Enhances safety by eliminating the need for naked flames.

—

O-Ring Material Characteristics and Application

The rubber **O-ring** is crucial for the sealing and sanitary performance of the press-fit system. **Aquinox O-rings** use **imported rubber materials** and are processed under strict control. They comply with **GB/T 19228.3-2012** and **GB/T17219** for drinking water, with **EU DVGW standard** options available. Multiple types of O-rings are offered for diverse applications, including water treatment, oil & gas, and HVAC, ensuring resistance to hot water, ageing, and common additives.

Material	Color	Temperature Range	Max. Working Pressure (MPa)	Application
EPDM	Black	-40°C – 150°C	2.5	● Hot & Cold Water ● Drinking Water System
SI	White	-20°C – 200°C	2.5	● Hot & Cold Water ● Drinking Water System
SI (Import)	Claret	-20°C – 200°C	2.5	● Fire ● Steam ● Solar
NBR	Yellow	-30°C – 120°C	2.5	● Gas & Oil
HNBR	Green	-30°C – 180°C	2.5	● Gas
FKM	Brown	-30°C – 250°C	2.5	● Industrial & Chemical

—
